Leak Detection in Edwards, CO — Find It Before You Open a Wall
A water bill that jumped 30% with no change in usage. A ceiling stain that keeps reappearing after patches. A soft spot in the flooring with no visible source. These are signs of a hidden leak that's been running long enough to cause structural damage — and every day it runs is money lost and damage accumulating. Masters Plumbing Service uses acoustic ground microphones, thermal imaging cameras, and precision pressure testing in Edwards, CO to locate leaks without speculative demolition.
No single detection method works for every leak scenario. Our technicians are trained on four distinct approaches and select the right tool — or combination of tools — based on the pipe type, building construction, and leak characteristics.
🎙️
Acoustic Ground Microphone
Pressurized supply line leaks create a distinctive low-frequency sound as water escapes the pipe and contacts surrounding soil or structure. Our acoustic listening devices amplify this signal, filtered for background noise, so we can walk a grid pattern and triangulate the loudest point — often to within 6–12 inches of the actual break.
🌡️
Infrared Thermal Camera
Thermal imaging is particularly effective inside insulated wall cavities and for finding the extent of moisture spread beyond the immediate leak point. It tells us not just where the pipe is failing but how far the moisture has already traveled.
📉
Pressure Decay Testing
We isolate the supply system, pressurize it to operating pressure, and monitor pressure over a timed hold period. Any pressure drop confirms active water loss from the supply side. By isolating zones — hot side vs. cold side, section by section — we narrow down which branch of the supply system is leaking before the detection phase begins.
💨
Tracer Gas Detection
For leaks that don't produce sufficient acoustic signature — very slow leaks, polyethylene pipe, or leaks deep under concrete — we can introduce a nitrogen/hydrogen tracer gas mixture into the isolated pipe and use a calibrated gas detector at the surface to find where the gas escapes. The detection sensitivity can locate leaks that produce no discernible pressure drop during a standard timed test.
What We Locate
Leak Detection for Walls, Slabs, Pools & Irrigation in Edwards
Our detection service covers the full property, not just the obvious locations.
Under Slab
Slab Leak Detection
Confirmed slab leak location is documented with a marked point on the floor and provided to you in the written detection report, with coordinates relative to fixed reference points for the repair crew.
In-Wall
In-Wall & Ceiling Leak Detection
We document the thermal anomaly, mark the approximate pipe location, and recommend a minimal access cut rather than a wide wall opening.
Water Main
Underground Supply Line Detection
Supply lines between the meter and the structure run underground and are vulnerable to corrosion, ground movement, and tree root damage. A main supply line leak shows as unusually high meter usage with all interior fixtures off, sometimes with wet ground or sinkholes along the line path. Acoustic detection locates the failure in the buried line precisely enough to minimize excavation footprint.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Pool plumbing — suction and return lines buried between the equipment pad and the pool shell — can develop leaks at fittings or in the pipe body that appear as unexplained water loss. We pressure-test the pool plumbing circuit, isolate the return and suction lines separately, and use acoustic detection to find which line and where.
Commercial
Commercial Property Leak Detection
Commercial water loss from undetected leaks often shows up as elevated utility bills for months before physical evidence appears. We can assess a commercial building's plumbing system for suspected leaks at the property owner's or property manager's request.
Documentation
Leak Detection Report for Insurance
We format detection reports specifically for insurance submission and can provide documentation on our detection equipment and methodology to claims adjusters on request.
From Water Bill Spike to Confirmed Leak Location — 4 Steps
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
This step confirms we're looking for a real leak rather than meter error or a normal appliance cycling.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
Within the isolated zone, we deploy thermal imaging first — scanning walls, floors, and ceilings for moisture anomalies. Then acoustic equipment confirms the specific pipe location and narrows it to the tightest possible point. Tracer gas is added if acoustic results aren't conclusive.
4
Written Report & Repair Options
Insurance claims: the report is formatted to support a claim for water damage from a concealed leak. We can provide supplemental documentation on request.
Customer Reviews
What Customers Say About Our Detection Service
★★★★★
High-efficiency home with a leak that defied normal detection. Water loss was slow — about 1.5 gallons per hour. The tech used tracer gas after pressure testing confirmed the loss but acoustic detection couldn't localize it clearly. Gas detection found the escape at a micro-fitting under the slab in the utility corridor. Impressive work.
— C. Thornton, Edwards
★★★★★
Ceiling stain in the living room kept coming back despite two drywall patches. Masters Plumbing Service ran the thermal camera and found the wet zone was traveling from a supply line joint 9 feet away and flowing down a horizontal framing member — explaining why the patch kept failing. They marked the actual pipe location, we opened 8 inches of wall there, and the repair held. No more stain.
— B. Osei, Edwards, CO
★★★★★
Commercial building where water costs were running 40% above baseline for six months. Masters Plumbing Service ran a systematic zone-by-zone pressure isolation across four floors, narrowed the loss to the third-floor kitchen supply branch, and located the failure with thermal imaging at a concealed valve body in the ceiling. No damage to the finished ceiling.
— T. Anand, Edwards, CO
Common Questions
Leak Detection Questions from Edwards, CO Property Owners
The most reliable self-check: shut off every fixture and appliance in the house, then watch the water meter for 15 minutes. Any movement — including the small leak indicator dial — means water is escaping the supply side somewhere. If the main meter dial moves with everything off, you have a leak. Call us to locate it.
The repair itself requires physical pipe access, which typically means a small, targeted opening. But that's a completely different proposition from opening large wall sections while searching for an unknown leak location.
For pressurized supply lines in concrete or metal pipe, acoustic detection is typically accurate to within 6–18 inches under ideal conditions — quiet environment, no interference from other water use, metal pipe conducting sound clearly. Thermal imaging is accurate to the size of the wet zone it reveals, which varies based on how long the leak has been running and how far moisture has migrated.
Yes. Our written detection report includes: technician credentials, equipment identification, pressure test methodology and results, detection method description, leak location with reference measurements, and supporting thermal imagery. This is the documentation format most insurance adjusters require to approve a concealed-leak water damage claim.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
Yes — and for most residential leaks, we can repair the failure the same day detection confirms the location. Our service trucks carry the repair materials for the most common supply line failures. We quote the repair as a flat-rate job separate from the detection fee, and you decide whether to proceed with us or take the detection report to your own plumber.
Service Area
Leak Detection Available Across Edwards, CO
Masters Plumbing Service provides professional Leak Detection for residential and commercial properties throughout Edwards and the surrounding Edwards, CO service area. Detection appointments available most weekdays and Saturdays.
